Fully Automated Fibre Filling System (Ref. 12186)

• Power: 26 kW<br> • Voltage: 380V, 50Hz, 3-Phase<br> • Productivity: Up to 1,500 kg/hr<br> • Compressor Required: ">8 kW at 8 bar<br> <br> System Components & Specifications<br> • Automatic Feeding Machine: 5500 × 1400 × 2300 mm | 1400 kg | 4.8 kW<br> • Fibre Opening Machine: 1800 × 1220 × 1050 mm | 750 kg | 6.05 kW<br> • Fan Conveying Machine (x2): 670 × 650 × 1350 mm / 950 × 600 × 910 mm | 60–90 kg | 2.2 kW each<br> • Storage Box (8 m²): 2700 × 1300 × 2750 mm | 650 kg | 3 kW<br> • Filling Machine #1: 1950 × 850 × 2050 mm | 650 kg | 3.7 kW - 2 nozzles <br> • Filling Machine #2: 1950 × 850 × 2051 mm | 651 kg | 4.7 kW - 2 nozzles <br> • Control Panel / Board<br> <br> Key Features<br> • High-efficiency fibre filling system designed for high-volume production<br> • Automatic feeding conveyor accepts up to 250 kg of uncarded fibre<br> • Long-tooth and multi-tooth rollers create light, airy fibre<br> • Large 8 m² storage box supports continuous output for up to four operators<br> • Suitable for filling pet beds, cushions, plush toys, and more<br> • Interchangeable filling nozzles for different product requirements <br> <br> <br>
